KUBOTA U17-5 MINI EXCAVATOR (55000091)

Kubota U17-5 Mini Excavator – Overview

Compact Strength, Smooth Control, and Outstanding Reliability

The Kubota U17-5 Mini Excavator combines impressive power, precision control, and unmatched versatility in a zero-tail swing design built for tight spaces. Designed for construction, landscaping, utilities, and groundwork professionals, this compact 1.7-tonne excavator delivers exceptional performance, fuel efficiency, and operator comfort for maximum productivity on every job.

Powered by the reliable Kubota D902-E4-BH-4EU Stage V diesel engine, the U17-5 produces 16.1 PS (11.8 kW) of responsive power with low fuel consumption and reduced emissions. This 3-cylinder, water-cooled engine ensures consistent torque and smooth operation, providing dependable performance even during demanding excavation tasks.

The U17-5 offers a maximum digging depth of 2,310 mm, a dumping height of 2,390 mm, and a lifting capacity of up to 460 kg at ground level (over front, blade down). Its zero-tail swing design allows safe and efficient operation in confined or urban spaces, while the variable track width, adjustable from 990 mm to 1,240 mm, provides easy access through narrow passages and enhanced stability when extended.

Kubota’s advanced hydraulic system ensures smooth, precise control for digging, grading, and lifting tasks. The two-speed travel system enables fast, effortless movement between work areas, while the robust undercarriage and high blade design improve ground clearance and durability.

Operator comfort is at the heart of the U17-5’s design. The spacious operator area provides an ergonomic layout with intuitive joystick controls, an adjustable suspension seat, and excellent visibility. Noise and vibration levels are kept low, allowing for comfortable operation throughout the day.

Safety features are standard, including a seatbelt alarm, travel lock levers, and ROPS/TOPS protection, ensuring secure operation in all conditions. Built to Kubota’s renowned standards, the U17-5 offers reliability, efficiency, and performance that stand the test of time.

Key Features

• Kubota D902 Stage V diesel engine – 16.1 PS (11.8 kW) for efficient, low-emission performance
• Maximum digging depth: 2,310 mm | Dumping height: 2,390 mm
• Lifting capacity: up to 460 kg at ground level (over front, blade down)
• Zero-tail swing design – ideal for confined or urban workspaces
• Variable track width: 990–1,240 mm for access or stability
• Advanced hydraulic system – smooth, responsive control for precise operation
• Two-speed travel system – easy manoeuvring between work zones
• Spacious, ergonomic operator area with excellent visibility and comfort
• Low noise and vibration levels for fatigue-free operation
• Standard safety features – seatbelt alarm, travel lock levers, ROPS/TOPS protection
• Durable Kubota build – strong undercarriage and reinforced components for long-term reliability

Specifications

Model	U17-5
Machine Weight (kg)	1705
Power (ISO 14396:2002) (kW (PS) / rpm)	11,8 (16,0) / 2300
Max Speed (km/h) low/high	2,3 / 4,4
Max Dig Depth (mm)	2290
Max Reach (mm)	3880
Max Digging force Arm/Bucket (kN)	27,7 l/min @ 216 kgf/cm²
Aux Flow 1	10,4 l/min @ 186 kgf/cm²
Aux Flow 2	10,4 l/min @ 186 kgf/cm²
Overall width (mm)	990 / 1300
Overall height (mm)	2370
Transport length (mm)	3550
