Kubota KC70H-4e –Overview
Smart Energy Solution for Clean and Efficient Material Handling
The Kubota KC70H-4e Smart Energy Solution is a compact, fully electric-powered tracked dumper designed to deliver powerful performance with zero emissions. Built for contractors, landscapers, and groundworkers who need quiet, efficient, and environmentally responsible material transport, the KC70H-4e sets a new benchmark in sustainable site productivity.
Powered by lithium-ion battery technology, the KC70H-4e offers impressive runtime and fast recharging, enabling operators to complete a full working day on a single charge under typical conditions. The zero-emission electric motor allows operation in low-emission zones, urban environments, and indoors—making it ideal for use in sensitive areas such as residential developments, greenhouses, tunnels, and enclosed worksites.
Despite its electric drive, the KC70H-4e sacrifices nothing in terms of performance. It maintains the same payload capacity of 700 kg as its diesel counterpart and delivers powerful, smooth travel through hydraulic transmission and robust rubber tracks. The dumper’s hydraulic high-tip skip enables efficient unloading directly into skips or trucks up to 1.43 m high, reducing manual handling and speeding up workflow.
Designed for operator comfort and ease of use, the KC70H-4e features simple fingertip joystick controls and intuitive dashboard displays for battery status and diagnostics. Its compact width of just 750 mm allows it to pass through standard doorways and narrow access points with ease—perfect for indoor and urban applications where space is at a premium.
Durability and reliability are key hallmarks of Kubota engineering. The KC70H-4e is built with high-quality components and a rugged steel chassis to handle challenging conditions while minimising maintenance requirements. Quiet, clean, and efficient, this electric tracked dumper helps businesses meet sustainability targets while maintaining Kubota’s reputation for performance and dependability.
Key Features
- Zero-emission electric drive – ideal for indoor and low-emission sites.
- Lithium-ion battery system – long working hours with rapid recharge capability.
- 700 kg payload capacity – delivers serious power in a compact footprint.
- Hydraulic high-tip skip – unloads directly into trucks or skips up to 1.43 m high.
- Compact 750 mm machine width – passes through standard doorways for easy access.
- Hydrostatic transmission – ensures smooth travel and precise control on all terrains.
- Low noise and vibration levels – enhances operator comfort and site safety.
- Rugged Kubota construction – engineered for durability, reliability, and easy maintenance.
Specifications
| Model |
KC70H-4
|
KC70VSL-4E
|
| Machine Weight |
654
|
740
|
| Max Loading Capacity |
700
|
700
|
| Fuel |
Electric
|
Electric
|
| Power ( kW/hp) |
48V/120AH
|
48V/120AH
|
| MaxSpeed (km/h ) |
2.0/4.0
|
2.0/4.0
|
| Operator Platform |
Stand
|
Stand
|
|
Undercarriage
|
Fixed |
Variable
|
| Skip Heaped Volume |
0,34
|
0,34
|
| Skip Level Volume |
0,28
|
0,28
|
| Overall Width (mm) |
750
|
758-1058
|
| Transport Height (mm) |
1358
|
1358
|
