KUBOTA DMC63100T MOWER (55000060)

Kubota DMC63100T Mower – Overview

Exceptional Productivity and Performance

The Kubota DMC63100T is a high-performance butterfly mower designed for professional farmers and contractors who demand maximum efficiency, durability, and precision in every cut. With an impressive 9.9 m working width, the DMC63100T delivers outstanding field capacity, helping you cover more ground faster while maintaining superior cutting quality and forage performance.

At its core is the fully welded Kubota cutterbar with triangular discs, engineered for strength, reliability, and long service life. This design provides a smooth, even cut with minimal crop contamination, ensuring high-quality forage every time.

The DMC63100T is equipped with a roller conditioner, ideal for delicate crops such as clover or alfalfa, ensuring gentle but effective conditioning for faster and more uniform drying. The two-speed conditioner rotor (600/900 rpm) allows adjustment based on crop type and field conditions, optimising output and protecting forage quality.

With its centre-mounted suspension, the mower offers excellent ground contour following, maintaining a consistent cutting height even on uneven terrain. The result is a cleaner cut, improved crop regrowth, and reduced soil contamination.

Kubota’s NonStop BreakAway system provides peace of mind and reduces downtime by automatically protecting the mower from damage when an obstacle is encountered — it simply pivots back and returns to position.

The compact vertical transport position ensures stability and safety when moving between fields, while the hydraulic spring adjustment and easy maintenance features make setup and operation simple and efficient.

Designed for large-scale productivity, durability, and minimal maintenance, the DMC63100T combines Kubota’s proven engineering with class-leading innovation to deliver maximum results with minimal effort.

Key Features

• 9.9 m working width for maximum field capacity
• Fully welded Kubota cutterbar with triangular discs
• Centre-mounted suspension for optimal ground following
• Roller conditioner for gentle, even crop handling
• Two-speed conditioner rotor (600/900 rpm) for crop flexibility
• Kubota NonStop BreakAway protection system
• Hydraulic spring adjustment for quick setup
• Compact vertical transport for easy movement between fields

Specifications

Models	Working Width	No of Discs	Conditioner	Power Req.
DMC63100T/DM64100T	9.80-10.20m	2×10	SemiSwing	150kW/200hp
DMC63100R/DMC64100R	9.80-10.20m	2×10	Roller	150kW/200hp
DMC63100T BX/DMC64100T BX	9.80-10.20m	2×10	SemiSwing	170kW/240hp
DMC63100R BX/DMC64100R BX	9.80-10.20m	2×10	Roller	170kW/240hp
